Light & Medium Duty Lathe Machines for Workshops

Lathe Machines by Industrial Machinery Corporation

Lathe Machines by Industrial Machinery Corporation thumbnail

Lathe Machines by Industrial Machinery Corporation additional view 1

Review Light & Medium Duty Lathe Machines for Workshops for your component and the required production operation.

Place the operation in the production route

The role of this equipment is to turn suitable metal workpieces using the selected lathe, workholding and cutting tools. Compare the incoming stock with the component required by the next manufacturing or assembly stage. Define workpiece material, maximum diameter, length, drawing and machining operations. The finished drawing should show which dimensions and surfaces this operation must produce.

Plan handling and changes between jobs

Review turning envelope, centre distance, spindle bore, chuck or between-centres holding and stock support, together with loading space and the movement of the component between stages. Compare light, medium and heavy-duty models using the component and workholding requirements rather than only the bed length. List the sizes and batch quantities before discussing output. Tool changes, handling and inspection should be included when assessing the proposed workshop arrangement.

Connect quality checks to machine selection

Agree how the component will be assessed for machined diameters, lengths, required finish and any specified cut threads. Identify the representative material and sample needed to establish the setup. Compare the listed models against the drawing and the operation, then ask IMC to state the supplied tools and accessories. Add the chosen options and quantity to the Quote List with the material, destination and power details so the offer reflects the actual production requirement.

Information to send with your enquiry

Workpiece material
Maximum diameter
Length
Drawing and machining operations

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Available options

Select the required options and add this machine to your quotation.

Available Options

Min And Max Diameter of the Job

Maximum Length Required

Expected Price

Purchase

Your selected configuration is stored in the existing Quote List flow for review before enquiry.

VIDEO REFERENCE

Machine Videos Gallery

No product-specific playlist is stored for this item yet. View IMC machine demonstrations and production videos in the main gallery.

View Machine Videos

TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

Industrial Machinery Corporation is one on the leading Lathe Machines Manufacturers in India having an experience of more than 10 years in manufacturing lathe machine. We have an experienced team of professions who are equipped with years of experience in producing lathe machines. Due to our sheer perseverance in providing our clients with the best, we have been acknowledged very well in the world of lathe Machines Company. We have build up a good dealer as well as satisfied clients’ network in major countries of the world. Our achievement is attributed to our dedicated and innovative employees and our supportive customers. At Industrial Machinery Corporation, we are committed towards quality assurance, after sale services and satisfaction of the customers. Being a reputed Lathe Machine Manufacturer of India, we have got a variety of lathe machines and here are few types of lathe machine that are manufactured at industrial machinery corporation unit situated at Ludhiana.

Light Duty Lathe Machine: this lathe machine, as the name suggests, is ideal for shaping or deforming small scale objects and these tasks are performed basically at workshops, tool-rooms etc. it is hard-core user-friendly which can be installed easily and once installed will give lathe of accurate shapes under supreme control over user controlled operations.

Medium Duty Lathe Machine: this lathe machine manufactured at industrial machinery corporation is suitably used in power plants, steel rolling mills, workshops, paper mills and tool rooms. It has been designed to produce enhanced functionality and high-operational output and best possible performances.

Heavy Duty Lathe Machine: this type of lathe machine is best used for performing to produce robust machine designs. The programming of this lathe machine is concluded in such a way that it gives long working hours to the clients alongside durability and most accurate outputs. It is best used to accomplish large scale metal and wood working tasks. It is a state-of art machine fitted with all latest technologies to make sure that it gives high quality results in lesser time with minimum human efforts applied.

Extra Heavy Duty Lathe Machine: extra heavy duty lathe machines works best for those who wish to fulfill their requirements of shaping or de-shaping very hard materials. Keeping this thing in view, this machine has been designed with an added endurance and high tolerance. Look wise this is a simplest of machines but when it comes of delivering performances, no machine can compete with its robustness and vigor.

Roll Turning Lathe Machine: this machine is specially designed to produce cylindrical rolls in rolling mills. It is a tough made and reliable machine which can be used in finishing and many other applications in power plants, steel rolling mills and heavy industries.

Following are the features of lathe machines manufactured by us at Industrial Machinery Corporation.

• 8 speed geared headstock

• Hardened gears

• Hardened and ground Spindle and Shafts

• Large 40 mm spindle bore

• Taper Nose spindle/ {A2-4 Spindle Extra}

• 2 HP main motor • Removable gap

• Apron lead screw / feed rod/ Third Shaft for reverse/Forward.

• Foot Paddle • Bottom mounted electrical.

• Automatic longitudinal and cross feeding

Specifications:

Model	BL - 4.5'	BL - 6'	BL - 8'	BL - 10'	BL - 12'
Length of Bed	4.5'	6'	8'	10'	12'
Width of Bed	300	350	400	450	500
Height of Centre	250	300	350	400	450
Swing Over Bed	500	600	700	800	900
Swing in Gap	700	800	950	1150	1300
Swing Over Saddle	325	375	450	500	550
Admit Between Centre	600	900	1300	1800	2250
Spindle Hollow	40	75	90	100	100
Power Required	1 H.P.	2 H.P.	2 H.P.	3 H.P.	5 H.P.
Lead Screw Pitch	2	2	2	2	2
Spindle Speed	6	6	6	6	6

Standard Accessories

Face Plate
Motor Plate
Steady Rest
Follow Rest
Full Norton / Semi Norton Gear Box
Gear Set
R/F Starter

Optional Accessories

Dog Chuck
True Chuck
Electric Motor, Pully

Specialization

Semi Gear Head Model (Belt
Hardened Bed for Long Life (Optional)
More Accurate
Extra Feed Shaft

Model	BL - 4.5'	BL - 6'	BL - 8'	BL - 10'	BL - 12'
Length of Bed	4.5'	6'	8'	10'	12'
Width of Bed	300	350	400	450	500
Height of Centre	250	300	350	400	450
Swing Over Bed	500	600	700	800	900
Swing in Gap	700	800	950	1150	1300
Swing Over Saddle	325	375	450	500	550
Admit Between Centre	600	900	1300	1800	2250
Spindle Hollow	40	75	90	100	100
Power Required	1 H.P.	2 H.P.	2 H.P.	3 H.P.	5 H.P.
Lead Screw Pitch	2	2	2	2	2
Spindle Speed	6	6	6	6	6

Standard Accessories

Face Plate
Motor Plate
Steady Rest
Follow Rest
Full Norton / Semi Norton Gear Box
Gear Set
R/F Starter

Optional Accessories

Dog Chuck
Motor Pully
Electric Motor
R/F Starter

Model	LB - 10'	LB - 12'	LB - 14'	LB 18'	LB - 20'
Length of Bed	10'	12'	14'	18'	20'
Width of Bed	500	500	550	600	650
Height of Centre	450	450	500	550	550
Swing Over Bed	875	875	975	1050	1050
Swing in Gap	1300	1300	1400	1550	1550
Swing Over Saddle	550	550	600	650	650
Admit Between Centre	1800	2250	2700	3600	4050
Spindle Hollow	90	104	104	104	104
Power Required	3 H.P.	5 H.P.	7.5 H.P.	10 H.P.	10 H.P.
Lead Screw Pitch	2	2	2	2	2
Spindle Speed	6	6	6	6	6

Standard Accessories

Face Plate
Motor Plate
Steady Rest
Follow Rest
Full Norton / Semi Norton Gear Box
Gear Set
R/F Starter

Optional Accessories

Dog Chuck
Motor Pully
Electric Motor, Pully.

Model	LBL - 4.5'	LBL - 6'
Length of Bed	4'6""	6'
Width of Bed	250	250
Height of Centre	200	200
Swing Over Bed	390	390
Swing Hollow	42	42
Admit Between Centre	500	1000
No. of Spindle Speeds	8	8
Range of Spindle Speeds	50 - 1200	50 - 1200
No. of Feeds	32	32
Range of T.P.I. Thread	4 -- 56	4 -- 56
T.P.I. of Lead Screw	4	4
Power Requirement	2 H.P.	2 H.P.

Standard Accessories

Face Plate
Motor Plate
Steady Rest
Follow Rest
Gear Set
R/F Starter

Optional Accessories

Dog Chuck
Motor Pully
Electric Motor, Pully.
Full Norton Gear Box
Extra Feed Shaft

Specialization

Hardened Bed for Long Life (Optional)
More Accurate

Model	LL - 4.5'	LL - 6'	LL - 7'	LL - 9'	LL 10'	LL - 12'
Length of Bed	4.5'	6'	7'	9'	10'	12'
Width of Bed	300	300	320	320	395	395
Height of Centre	225	225	250	250	375	375
Swing Over Bed	425	425	475	475	725	725
Swing in Gap	550	550	600	600	850	850
Swing Over Saddle	225	225	300	300	275	275
Admit Between Centre	500	950	975	1575	1875	2450
Spindle Hollow	53	53	53	53	78	78
Power Required	1 H.P.	2 H.P.	2 H.P.	3 H.P.	3 H.P.	5 H.P.
Lead Screw Pitch	4	4	4	4	4	4
Spindle Speed	8	8	8	8	8	8

Frequently Asked Questions About Lathe Machines

What details should I send for Lathe Machines?

Provide the component drawing, material and operations such as turning, facing, boring or threading. Include workholding details and the available workshop power supply.

What is Lathe Machines used for?

Lathe selection begins with the largest workpiece and the operations to be performed. Turning length, workpiece diameter, bore requirements and tooling all influence the suitable configuration.

What workpiece drawing is useful when selecting a lathe?

Show the largest diameter, overall machining length, material and required operations. Include any bore, thread or accuracy requirements and ask for the proposed tooling and workholding details.
