Review Hydraulic Pipe Thread Rolling Machine for your component and the required production operation.

Place the operation in the production route

The role of this equipment is to form external threads on suitable pipe workpieces with a matched three-roll hydraulic configuration. Compare the incoming stock with the component required by the next manufacturing or assembly stage. Define pipe diameter, wall thickness, material, thread drawing and desired length. The finished drawing should show which dimensions and surfaces this operation must produce.

Plan handling and changes between jobs

Review three-roll dies, mounting fit, pipe support and the intended feed arrangement, together with loading space and the movement of the component between stages. Pipe wall section and material suitability are important; outside diameter by itself does not establish rolling compatibility. List the sizes and batch quantities before discussing output. Tool changes, handling and inspection should be included when assessing the proposed workshop arrangement.

Connect quality checks to machine selection

Agree how the component will be assessed for thread profile, mating-part fit and pipe condition after forming. Identify the representative material and sample needed to establish the setup. Compare the listed models against the drawing and the operation, then ask IMC to state the supplied tools and accessories. Add the chosen options and quantity to the Quote List with the material, destination and power details so the offer reflects the actual production requirement.

Information to send with your enquiry

  • Pipe diameter
  • Wall thickness
  • Material
  • Thread drawing and desired length

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Tags

Hydraulic Thread Rolling Machines 3Roll, Hydraulic Thread Rolling Machine 2 Roll, Ludhiana Punjab India, thread rolling dies manufacturers, thread rolling machine, Thread Rolling Dies at Best Price in India, Hydraulic Thread Rolling Machine at Best Price in India, Thread Rolling Machines Two Roll Type, thread rolling machine manufacturers in india
CONFIGURE YOUR MACHINE

Available options

Select the required options and add this machine to your quotation.

Available Options


Your selected configuration is stored in the existing Quote List flow for review before enquiry.

TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

Industrial machinery corporation is an eminent name in the list of manufacturers of Thread Rolling Machines India as our approach towards our responsibility is quite professional and hence we are acknowledged amongst the very few manufacturers of Thread Rolls India who have experience of over a decade in manufacturing not just Pipe Thread Roller but also Thread Rolling Machine, Hydraulic Thread Rolling Machines, Cam Thread Rolling Machines, Gear Serrationing Rolling Machine, Thread Rolling Dies, Serration / Knurling Rolling Dye. Industrial Machinery Corporation was formed in the year 2001 and since then, we have been working in this field and have gained rare expertise in the business of Thread Rolling Machines. The Pipe Thread Rollers or the pipe threading machines that we manufacture here at Industrial Machinery Corporation have now proven their precision, practicality, durability, excellence in device design, and rigid structure with excellent outlooks. The Thread Rolling Machines have proved that they are ready to face any type of challenge or responsibility coming their way. Our sole aim while creating these Pipe Thread Rollers is to provide world-class quality without letting the price go beyond the reach of our customers. We arrange our production lines – thread rolling machine production and has won undisputed adoption and honors from the customers for both the local market and abroad. Industrial Machinery Corporation has come up with Thread Rolling Machines India 3 roll which was released after a huge series of tests, quality checks, and safety aspects. Let’s have a quick assessment of this Pipe Thread Roller, as to what it has in for the customers.

The following are the features of the Pipe Thread Roller:

This Pipe Thread Roller operates on the hydraulic principle the simultaneous and concentrated three force applied at 120 degrees simultaneously makes sure that there is stability at every step during the rolling.

The elimination of the support blade ensures better finishing of every piece. This Pipe Threading Machine is suitable for rolling pipes, lapping work, and threading with high-class precision, and mass production.

The rolling time and the length can be adjusted according to the needs and the slide-way feeding is driven by a hydraulic unit, precision in positioning, and power without any distortion.

This Pipe Threading Machine is specially designed to suit Long length screws, ACME screws, Ball Screws, machine parts, tools, and automobile/motorcycle parts.

This machine also provides full assistance while working on rolling pipes, lapping work, threading with high-class precision, and for mass production of Scaffolding pipe jack and solid jacks screws, etc.

Along with this Pipe Threading Machine, we also provide all kinds of thread rollers, work rest blade guides, and some other precise tools at no extra cost. We have this facility for our clients to get their machines customized as per their specific demands and requirements.

Circular Thread Rolls
These thread rolls are used on thread thread-rolling machines. These rolls come in a set of two and three pieces manufactured from D2, D3, and M2 Material to suit any type of machine. The maximum values specified above can not be achieved simultaneously

Specifications:
Model   IMC-3R-25 IMC-3R-50IMC-3R-75
Work RangeOut Side Diameter Thread Length in Feed Thread Length Through Feed

(8-25 MM) (1/2"- 1")(38 MM) (1.1/2") (Indefinite) (Indefinite)

(25-50 MM) (1"- 2")(50 MM)(2") (Indefinite)(Indefinite)

(32-75 MM) (1.1/4"- 3") (75 MM) (3") (Indefinite) (Indefinite)
Roll DiesMax. Out Side Dia. Max. Inside Dia Spindle Box140 60 40140 60 40170 80 54
MotorFor Roll Spindle3 H.P.3 H.P.7.5 H.P.
3 Phase ACFor Hydraulic System1 H.P.1 H.P.3 H.P.
Coolant Pump0.1 H.P.0.1 H.P.0.1 H.P.


thread rolls                                                               circular thread roll

Thread Rolling Dies 3 Roll Type                                                                              Thread Rolling Dies 2 Roll Type

IMC Thread rolls are used on thread rolling machine. These rolls come in the set of two and three pieces manufactured from D2,D3 and M2 Material to suit any type of machine. For any specification of thread such as ISO Metric Din Whiteworth America, Trapozodical, Acme etc

Frequently Asked Questions About Hydraulic Thread Rolling Machines 3 Roll

Send tube outside diameter, wall thickness, material grade and thread drawing. Ask IMC to review the component and die requirements before selecting the machine configuration.

A three-roll hydraulic thread rolling machine forms external threads with a three-roll arrangement. For hollow components, wall thickness and material behaviour must be assessed along with the thread geometry.

Send the tube outside diameter, wall thickness, material grade and finished thread drawing. Ask for a trial on representative stock to review the thread and finished tube dimensions.
