Rod Tapping Machine for Internal Threads

Internal Pipe Threading Machine by Industrial Machinery Corporation
PRICE & QUOTATION
Starting From US$ 3,500
Choose options
Set quantity
Request quotation

Select the required model and specifications to request your quotation.

Review Rod Tapping Machine for Internal Threads for your component and the required production operation.

Place the operation in the production route

The role of this equipment is to make internal threads by tapping prepared holes in compatible pipes and bored rod components. Compare the incoming stock with the component required by the next manufacturing or assembly stage. Define hole diameter and depth, blind or through-hole form, material, thread standard and pitch. The finished drawing should show which dimensions and surfaces this operation must produce.

Plan handling and changes between jobs

Review tap selection, tap holding, component alignment and chip-clearance arrangements, together with loading space and the movement of the component between stages. Rod tapping here means an internal thread in a prepared bore, rather than external threading of a solid rod. List the sizes and batch quantities before discussing output. Tool changes, handling and inspection should be included when assessing the proposed workshop arrangement.

Connect quality checks to machine selection

Agree how the component will be assessed for internal thread size, useful depth and acceptance with the specified gauge or mating thread. Identify the representative material and sample needed to establish the setup. Compare the listed models against the drawing and the operation, then ask IMC to state the supplied tools and accessories. Add the chosen options and quantity to the Quote List with the material, destination and power details so the offer reflects the actual production requirement.

Information to send with your enquiry

  • Hole diameter and depth
  • Blind or through-hole form
  • Material
  • Thread standard and pitch

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Tags

Threading Machines, pipe threading die head, threading die head, Internal Pipe Threading Machine, Threading Taps, Internal Threading tap, internal threading tools, Threading Tap, Internal Threading Machine
CONFIGURE YOUR MACHINE

Available options

Select the required options and add this machine to your quotation.

Available Options


Your selected configuration is stored in the existing Quote List flow for review before enquiry.

Product Videos

View full playlist on YouTube
TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

Industrial Machinery Corporation is a pioneer company indulged in manufacturing, exporting and supplying Internal Threading Machine and thread rolling machine for a long period of more than 10 years now. In these 12 years, we have gained enough experience and expertise to feel and understand all the requirements of the company. The Internal Threading Machine manufactured at Industrial Machinery Corporation is all crafted using the best quality raw material to make sure that when the finished product reaches in the hands of the customers, they are unable to find any flaw or fault in the threading machine. We give special attention to towards the raw material as we are aware that stuff made out of a good quality raw material will ensure hassle-free and efficient work-flow while in the business. The Internal Threading Machine or thread rolling machine made at Industrial Threading Machine are tailor-made which will allow cutting of thread up to 150 M.M. The use of Internal Threading Machine could be found widely in various industrial sectors. Five speed gear box is fitted in this Internal Threading Machine which the users to manufacture up to eighty pieces in an hour. Apart from these qualities, Internal Threading Machine manufactured at industrial machinery corporation is absolutely customer-centric all allows the user to have benefits of customization as per their specific requirements.

The machine crafted at Internal Threading Machine is truly sophisticated and classy and are the masterpiece of engineering. All the machines manufactured at Internal Threading Machine are built as per the standards set by international society and comply with all the rules and standards and sit high on parameters of efficiency, durability, strength, robustness and competence. These are fabricated using high grade raw material, which not only ensures that the machine will be able to resist wear and tear, but also prove to be resistant against breakage and abrasion. Internal Threading Machines manufactured at Industrial Machinery Corporation are designed in such a way that minimum of human interference would be required on this threading machine. The modus operandi of this machine is so smooth that the work given to this threading machine is finished without any much endeavour and wit reduced human efforts. The way these threading  machines are fabricated, the eminence assessment panel, ensures that there are no expected breakdowns, during operation.

Following are the standard features that Industrial Machinery Corporation provides in its Internal Threading Machine:

• Trapezoidal thread (as per IS - 12818)

• Square Thread

nd the following are the optional features that we provide in our Internal Threading Machine as per the requirements of the customers.

• Robust and Study design

• AC Servo and PLC operated

• Fast threading compared to conventional threading machine

• No setting is required for different pipe diameter

• No change of saw for internal and external thread

Specifications:

Model No.  1/2” to 2”1/2" to 3"
Threading length can be cut   150 MM150 MM
Number of speed in gearbox    55
Production per hour    80 Pcs.80 Pcs.
Electrical Motor    3H.P. 960 RPM5 H.P. 960 RPM

Frequently Asked Questions About Internal Pipe Threading Machine

Send the bore diameter, thread standard, thread length and component drawing. State whether the hole is through or blind and identify the workpiece material.

Internal pipe threading produces a thread inside a suitable pipe or component bore. Access to the bore, thread depth and the required tooling determine the setup to review.

Give the existing bore diameter, available thread depth and required internal thread specification. Include the pipe material and holding length so tool access and workholding can be reviewed.
